Cat6 Plenum Bare Copper Network Cable
$189.99 – $195.00
★ Free Shipping
★ 23AWG 4-Pair conductors 10Gigabit
★ Unshielded twisted pairs – U/UTP
★ Bandwidth tested up to 550 MHz
★ Supports PoE++ (802.3bt) 4PPoE, up to 90W
★ Compliant with ANSI/TIA/EIA-568B.2
★ ISO/IEC 11801 Standards. RoHS Compliant
★ Fluke Test Passed over 90m
$189.99 – $195.00
Overview
- Description
- Additional information
- Reviews (4)
Description
Etek Cables Our Cat6 Plenum Bare Copper 1000ft Plenum CMP Rated UTP Bulk Ethernet Cable is Designed to distribute data, voice and video with applications up to 550Mhz. Our CAT6 Plenum CMP Rated Cable conductors featuring 23 AWG 4 Pairs with unshielded twisted pair (UTP) are Solid Bare Copper, which insures performance with high speed Gigabit Ethernet. Etek Cables is the perfect fit for reliable installations where the cable will be used indoors.
It also Supports Ethernet 100BASE-TX, 100BASE-VG and 155 ATM. Particularly suited for high bandwidth applications such as 622 ATM. Wideband Ethernet 1000BASE-T and emerging applications with anticipated data rate.
FEATURES:
§ Cat6 Plenum CMP Rated Cable
§ Low Smoke Plenum Rated Jacket
§ Designed for Indoor Plenum Rated indoor handling space
Installations
§ High-Performance Data Communications Cable
§ Tested up to 550Mhz
§ Flame-Retardant Plenum Rated jacket
§ Designed for Indoor Plenum Rated Installations
§ Category 6 Unshielded Twisted Pair (UTP) Cable
§ 4-Pair Easily Identified Color Striped Pairs
§ 23 AWG Solid Bare Copper Conductors
§ Excellent Attenuation and Crosstalk Characteristics
§ Cat6 1000ft cable available in Easy Pull Box
§ Suitable for local area network (Lan)
§ 0.5 mm thickness of Plenum jacket
§ Excellent Attenuation and Cross talk Characteristics
§ Available in Blue Color
§ Length 1000ft
CONDUCTOR:
§ FEP Insulation
§ 23 AWG, 0.58mm Dia.
§ Min Point Thickness = 0.207mm
§ Insulation Dia. = 1.02mm
§ Twisted Pair Dia.= 2.02mm
§ Avg. Thickness = 0.225mm
CERTIFICATION:
§ National electric code (NEC)
§ Compliant with ANSI/TIA/EIA-568B.2, ISO/IEC 11801 Standards.
§ RoHs compliant
Core Features:
-
23 AWG Solid Bare Copper Conductors provide strong conductivity, low resistance, and support reliable, high-speed data transfers.
-
Plenum (CMP) Rated Jacket ensures fire safety, making the cable suitable for air ducts and areas requiring low smoke emissions in case of fire.
-
Performance Speeds: Handles Gigabit Ethernet up to 328 ft and 10 Gigabit Ethernet up to 165 ft, depending on installation environment.
-
Meets Industry Standards: cETLus, UL, RoHS-3, ANSI/TIA-568.2-E compliant, ensuring high manufacturing quality and safety.
-
Installation-Friendly: Many variants include an internal spline for enhanced structural support, reduced kinking, and easier cable termination. Sequential footage markings aid installation.
Where It Shines:
Ideal for installation in plenum spaces such as drop ceilings or air circulation areas. The CMP rating is often required by building codes in these environments.
Shielded versions (F/UTP or FTP) protect against electromagnetic interference (EMI)—perfect for commercial buildings or dense electronic setups.
