Cat6 Plenum Shielded 1000ft Bulk F/UTP 550Mhz Cable Black


198 in stock

SKU: EC-CAT6-P-STP-BL-2 Categories: , Tags: ,




Bulk Cat6 Plenum Shielded 1000ft Blue F/UTP 550MHz Cable

The bulk Cat6 plenum shielded cable is a cutting-edge ethernet cable for high-speed networking applications. It features 4 (23AWG) twisted pairs of 100% pure bare copper conductors which are covered with a protective sheath to keep attenuation and all sorts of crosstalks out of your network.

The data transfer rate of this pure copper Cat6 plenum cable is up to 1 Gbps over a run length of 100 meters and up to 10 Gbps over 50 meters of cable run length. For high-performance ethernet network applications, the 550 MHz bandwidth capacity of this shielded bulk Cat6 plenum cable is ideal. It complies with RoHS, EIA/TIA standards.

The Blue jacket on the 1000ft bulk cat6 plenum shielded cable is CMP-rated (Communications Multipurpose, Plenum) plenum. It is highly resistant to extreme environmental conditions such as humidity, heat, and sub-zero temperatures. This Blue jacket of the Cat6 plenum is thick enough to resist crosstalk and thin enough for easy installation. It works at optimum capacity between the extreme temperatures of -20 to 80°C. For the ultimate easy installation, it comes on a wooden spool that is guaranteed to work smoothly.

This bulk Cat6 plenum shielded cable is a perfect choice for high-performance ethernet applications such as ANSI X3T9.5 TP-PMD (FDDI), ATM PMD 155 Mbps IEEE 802.3 Fast Ethernet:10 Base-T, 100 Base-T4, PoE, PoE+, PoE++, 100 Base-X IEEE 802.5:4/16 Mbps Token Ring, and IEEE 802.12:100 Base-VG.

The bare copper conductor of this shielded Cat6 ensures the longevity and efficiency of the cable. Also, in the plenum spaces are your building is safe with the pure copper Cat6 cable because of the minimum EMI (electromagnetic interference) entertaining characteristics of the conductor.

It comes with the legendary 10-year warranty (Terms and Conditions apply)  and 24/7 professional customer support.

Weight 41 lbs
Dimensions 11 × 15 × 15 in
Color: Blue

1000 FT

Cable Jacket:

F/UTP Plenum Rated


Wood Spool


100% Pure Copper Solid Conductor



Installation Temp:

-10℃ to 60℃


4 Twisted Pairs

Wire Gauge:
